DN63CF Quartz viewport, Deep-UV quality
1.210,00 € ex. VAT
in stock
in stock
Product description
DN63CF quartz viewing window, DUV quality, viewing diameter 68mm
Material: Corning HPFS 7980 Fused Silica
Homogeneity class: A
Inclusion class: 0
Transmission: >99.8% from 248nm
Polish: 20/10 Scratch/Dig
Flatness: λ/4@632nm
Parallelism: < 10 arc seconds
| Vacuum Suitability | |
|---|---|
| Flange Type | |
| Flange Name | |
| Flange Material | |
| Flange Style | |
| Min. Operating Temperature (°C) | |
| Max. Operating Temperature (°C) | |
| Part Type | |
| Viewport Diameter (mm) | |
| Viewport Material | |
| Coating | |
| Transmitted Wavefront Distortion (TWD) | |
| Polish | |
| Parallelism | |
| Inclusions | |
| Homogeneity |
